This is the Develon 12V 70A Relay Assembly, part number 301202-00845. A relay in general uses a small control signal to switch a larger current in a separate circuit, so a failed one can stop the circuit it controls from working. Order by the exact part number, because electrical parts that look alike can differ in ways you cannot see from the outside.
| Brand | Develon |
|---|---|
| Part number | 301202-00845 |
| Store SKU | 9566342 |
| Part type | 12V 70A Relay Assembly |
| Category | Electrical |
Machine models are not listed on this page. Check the part number against the machine's parts book, or send the model and serial number through the quote form so the parts team can confirm.
Match part number 301202-00845 to the entry in your machine's parts book or to the number on the old part. If you cannot confirm it that way, send the machine model and serial number through the quote form and the parts team will check it.
A relay lets a low-current control signal open or close a higher-current circuit. This keeps heavy current away from switches and wiring that were not built to carry it.
Common signs on relays in general include a circuit that works intermittently, a component that does not switch on or off when commanded, and a relay that clicks without the load responding. Heat damage, melted or discolored housings and corroded terminals are also common. Electrical faults can come from wiring, fuses or the load itself, so follow the machine's service manual to diagnose the circuit before replacing parts.
Have the part number (301202-00845), the machine model and serial number, and the quantity you need.
No. The store SKU (9566342) is RTL Equipment's own reference. The manufacturer part number is 301202-00845, and that is the number to use when checking a parts book or matching an old part.
